ArenaTM
我们一直追求创新。
原创力激活你的感官。
抛光
| 特点 | 单位 | 5 |
| 遇火表现UNE-EN-ISO 9239-1:2002 & ISO 1716:2002 | 欧洲等级标准 | A2fl s1 |
| 热膨胀系数UNE EN 14617-11:2006 | ºC-1 | 2.06 x 105 |
| 防变形UNE EN 14617-2:2005 | 兆帕 | 45 – 55 |
| 耐冲击性UNE EN 14617-9:2005 | J | 8 – 11 |
| 防滑性UNE EN 14231:2004 | USRV | 6 湿度37 干度 |
| 吸水性UNE EN 14617-1:2005 | % | 0.06 – 0.08 |
| 表观密度UNE EN 14617-1:2005 | kg/m3 | 2.350 – 2.450 |
| 耐磨性UNE-EN 14617-3:2005 | mm | 26 – 28 |
| 耐化学性UNE EN 14617-10:2005 | C4 | C4（该材料在受到酸碱侵蚀8小时后至少保持80%的反射率参考值） |
| 耐磨硬度UNE EN101瓷砖。 | 莫氏硬度检测 | 6 -7 |
该表中数值仅为参考，因此不具有约束力。
欲了解更多信息，请联系我们技术部门。
技术规格
规格
品质认证
 | Certificate for the quartz product range referring to building and construction products according to fire resistance classes, as tested by AFITILICOF, Center for Fire Testing and Research (Association for the Promotion of Research and Fire Safety Technology) pursuant to IMO Resolution A.653 as per IMO FTPC Code Resolution MSC 61 (67). |
 | Contact with Food Certificate COMPAC Technological Quartz products comply with European Regulation CE 1935/2004 for objects intended for contact with food. |
 | Greenguard mark This certificate issued by the Greenguard Environmental Institute guarantees that COMPAC products comply with indoor air quality standards covering volatile organic compounds (VOCs). The seals granted are Greenguard Indoor Air Quality Certified and Greenguard Children & Schools Certified, with the latter being one of the strictest standards in the industry. |
 | NSF Certification NSF Certification, from a recognized non-profit organization in the United States certifying public health, safety and environmental standards, means that COMPAC products are safe and hygienic materials for use in direct contact with food and foodstuffs of all kinds. |
 | BIO RESINS. Incorporating BIO resins from renewable plant sources is a very important technological advance to the market and benefits the entire distribution channel, especially in the handling by fabricators because of its lower shrinkage and internal stresses, supports better the bending, increases its impact resistance, cracks and cutting fissures, minimizing the slabs’ curvature during the storage and, due to its hardness, makes easier the polishing and finishing work. |
 | The U.S. Green Building Council (USGBC) is transforming the way we design, build, maintain and operate our buildings, homes and communities.USGBC is committed to a prosperous and sustainable future through cost-efficient and energy-saving green buildings. |
 | Cradle to Cradle Certified™ Bronze, a certificate that guarantees the sustainable characteristics of this innovative material created from 100% recycled glass. An international recognition that evaluates the products and their manufacturing process to ensure that the premises of the circular economy are met. |
 | IQ Circular Science, the responsible sense of COMPAC, the philosophy of respect for the environment that we have been working on for years. All of our portfolio designs are produced sustainably with 100% renewable energy and 98% of the water used in the production process is recycled. In addition, IQ Circular Pro includes recycled raw materials. Similarly, all designs contain little or no Respirable Crystalline Silica (RCS). |
 | HPD CERTIFICATE. Health Product Declaration® (HPD) Collaborative is an association representing the full spectrum of the building industry, that certificates the improvement of the information’s transparency and material health in buildings and the environment. |
 | Environmental Product Declarations (EPDs). Environmental Product Declarations (EPDs) present relevant and verified environmental information about goods and services from a life cycle perspective. |
质量证书
技术文件
- Genesis Collection 目录 (English) 石英石 下载
- Unique Collection 目录 (English) 石英石 下载
- 技术数据表 (English) 石英石 (2025) 下载
- 安全数据表 (English) 石英石 下载
- 台面设计安装手册 (English) 石英石 下载
- 石英石的安装技术建议 (English) 石英石 下载
- 保修条款及条件 (English) 石英石 下载
- 环保产品声明 石英石 下载
- Declaration of performance CE - Family 1 (English) 石英石 下载
- Declaration of performance CE - Family 2 (English) 石英石 下载
- Declaration of performance CE - Family 3 (English) 石英石 下载
- Declaration of performance CE - Family 4 (English) 石英石 下载
- Declaration of performance CE - Family 5 (English) 石英石 下载
- Declaration of performance CE - Family 6 (English) 石英石 下载
- 清洁、保护和维护手册 (English) 石英石 下载
